CarteZcash

CarteZcash takes Zcash and turns it into a Cartesi RollApp. Created for the 2024 Cartesi Hackathon.

Github Repo (description also in Readme)

(note in the demo video the amount withdrawn to L1 is incorrectly calculated. This has been fixed since the demo was recorded)

Motivation

The Zcash shielded pool is one of the most trusted private cryptocurrency protocols that has stood the test of time. Actually obtaining and using Zcash however is a poor user experience that generally requires the use of a centralized exchange. What if you could shield your Eth assets directly from Ethereum by depositing them into a Zcash L2? That is what CarteZcash allows you to do!

How It Works (Detailed Description)

Architecture

CarteZcash takes parts of the Zebra Zcash client and uses them to build a mini version of the protocol called we call TinyCash. This is similar to how Optimism uses minigeth for the Ethereum state transition.

TinyCash is Zcash but with the following changes:

• All network upgrades up to NU5 are applied in the first block
• Each block contains only a single coinbase transaction and up to one user transaction
• No checking of proof-of-work
• No miner rewards- Transaction fees not enforced

TinyCash then runs inside the Cartesi machine to produce a fully functional rollup.All interactions with the L2 are done via the Cartesi contracts. Deposits, transactions and withdrawals are all supported.

Deposits

Using Portals it is possible to deposit Eth into the rollup and have it minted as CarteZcash Coins into a transparent Zcash address. This works by using the coinbase transactions that are used for miner rewards in regular Zcash.

Upon receiving an `AdvanceState` message that matches an Eth deposit action, CarteZcash instructs TinyCash to mine a new block with a coinbase that mints coins to the wallet address decoded from the `execLayerData` field. These new minted coins are transparent (not shielded) but can be made anonymous by making another transaction into the shielded pool.

Transfers

CarteZcash is able to process regular Zcash transactions produced and signed by any Zcash wallet. This includes private shielded transactions! The prepared transactions just need to be serialized and then sent to CarteZcash via the InputBox contract.

Withdrawals

To withdraw from the CarteZcash L2 and get your coins back on L1 you simply cast your coins into the fires of Mt Doom!

What this means is you make a transparent transaction sending your coins to the Mt Doom address "t1Hsc1LR8yKnbbe3twRp88p6vFfC5t7DLbs". This address has no private key so the coins can never be spent again.

CarteZcash watches for transaction to this address and when it observes one will issue a voucher to release the corresponding number of coins on L1.

Wallet Interface

CarteZcash integrates with existing Zcash wallets via the cartezcash-proxy component. The proxy exposes a GRPC interface that matches the lightwalletd specification. This allows any complaint wallet to read the blockchain state and request the require info to update the wallet balances.

The proxy is essentially an indexer that runs the same program as the Cartesi machine but with additional data storage and interfaces. Having the proxy allows the program running in the Cartesi machine to aggressively prune old block data which is no longer needed for verification but wallets might need for updating their balance. It also avoids having to use the `inspect` HTTP API to retrieve state and allows for using GRPC instead.

Challenges Faced

Building for the Cartesi Machine

One of the main early challenges in the project was getting the Zebra client to compile for RiscV. Doing so required patching two upstream crates (ring and rocksDB). These diffs for these fixes can be found at

• https://github.com/briansmith/ring/compare/main...willemolding:ring:willemolding/riscv-build-0.16.20
• https://github.com/rust-rocksdb/rust-rocksdb/compare/master...willemolding:rust-rocksdb:willemolding/riscv-support

With these patches in place and some minor modifications to the docker image for cross-compilation it was possible to build the full Zebra Zcash client for the cartesi machine.

Modifications to Zcash

The goal was to make as few modifications to the exiting Zcash client as possible. The required changes can be seen

https://github.com/ZcashFoundation/zebra/compare/main...willemolding:zebra:willem/tinycash

Unfortunately it was a little more than I hoped for mainly because a lot of Zcash network parameters were hard-coded. For example Zebra can only be configured for either Mainnet or Testnet and within these known networks there are predetermined height for upgrades and known historical checkpoint blocks.

The main changes made were to apply all Zcash historical chain upgrades in the first block and to disable any consensus related checks (e.g. proof-of-work, fork selection). All round only a few hundred line changes were needed (mostly deletions).

Wallet Integration

One of the early goals for the project was to be able to integrate with the existing Zcash ecosystem wallets and tools. This also proved a bit tricky due to hard-coded network parameters. Getting a wallet to work requires some minor changes around checkpointing to remove hard-coded historical blocks. The wallet also had to be configured to include spends to pay the miner fees as they are not required for CarteZcash.

Integrating with the Zingo CLI wallet proved pretty straightforward although some issues still remain around observing shielded pool balances.

Future Work

In its current form CarteZcash requires all transactions to be submitted via the InputBox contract on L1. This could be gas expensive as every shielded Zcash transaction includes a large ZK proof. A more efficient design would introduce a sequencer that takes these proofs and submits them in a batch. An even more efficient design would aggregate all the proofs in a batch together into a single proof and only submit that on L1. As the Zcash orchard shielded pool uses Halo2 this kind of aggregation is definitely possible!

Another approach might be to use blobs or a separate DA service to store the transaction data.

Hackathon Reflection

I anticipated that cramming the full Zcash client into the Cartesi machine was going to be the hardest part of this project but it turned out to be very simple. Aside from the initial build issues the client was able to run in the VM, including features such as caching the RocksDB to the filesystem, without any modifications.

In particular I was skeptical if it would be able to verify the Halo2 ZK proofs required for shielded transactions. Not only did this work but it was only perhaps 50% slower than running the verifier natively! Once I made this discovery I was pretty confident at being able to get everything to work.

The tooling from Sunodo was an absolutely pleasure to use and meant I was able to spend much less time setting up the build/test environment and spend a lot more time developing the core of the application in Rust.

This same process could likely be applied to any blockchain state transition as a strategy to turn it into a rollup with maximum code reuse.
